| SN. |
PART NO. |
DESCRIPTION |
QTY |
OEM PART NO. |
| 1 |
F300-05020001 |
CRANKSHAFT |
1 |
6CB-11410-00 |
| 2 |
F15-00000006 |
DOWEL PIN Ø6x12 |
4 |
93606-12019 |
| 3 |
F300-05020102 |
LOWER
TILE,CRANKSHAFT |
4 |
|
| |
F300-05020102-1 |
LOWER
TILE,CRANKSHAFT(Red) |
|
|
| |
F300-05020102-2 |
LOWER
TILE,CRANKSHAFT(Green) |
|
|
| |
F300-05020102-3 |
LOWER
TILE,CRANKSHAFT (Bule) |
|
|
| 4 |
F300-05020104 |
LOWER THURST SHEET |
2 |
6CB-11427-03 |
| 5 |
F300-05020101 |
UPPER BEARING |
4 |
|
| |
F300-05020101-1 |
UPPER BEARING RED |
|
|
| |
F300-05020101-2 |
UPPER BEARING GREEN |
|
|
| |
F300-05020101-3 |
UPPER BEARING BLUE |
|
|
| 6 |
F300-05020103 |
UPPER THURST SHEET |
2 |
6CB-11426-03 |
| 7 |
F300-05020300 |
CONNECT ROD BEARING
RED |
12 |
|
| |
F300-05020300-1 |
CONNECT ROD BEARING
RED |
|
|
| |
F300-05020300-2 |
CONNECT ROD BEARING
GREEN |
|
|
| |
F300-05020300-3 |
CONNECT ROD BEARING
BLUE |
|
|
| 8 |
F300-05020402 |
PIN,PISTON |
6 |
6CB-11633-00 |
| 9 |
F300-05020403 |
CIRCLIP,PISTON PIN |
12 |
K0F-A3233-00 |
| 10 |
F300-05020400 |
PISTON RING ASSY |
6 |
6GR-11603-00 |
| 11 |
F300-05020301 |
PISTON |
6 |
6CE-11631-02 |
| 12 |
F300-05020201 |
BODY,CONNECTING ROD |
6 |
|
| 13 |
F300-05020202 |
COVER,CONNECTING ROD |
6 |
|
| 14 |
F300-05020203 |
BOLT,CONNECTING ROD |
12 |
63P-11654-10 |
| 15 |
F115-05000003 |
OIL SEAL A
φ85xφ103x7 |
1 |
93102-85008 |
